BODY AND CHASSIS
Frame: Welded Steel with E-Coat and DuraShield Powder Coat
Front Body and Finish: Injection Molded TPO
Rear Body and Finish: Thermoform ABS
DIMENSIONS
Length 106.5 inches
Width 46 inches
Overall Height:  75.5 inches
Wheel Base: 77.5 inches
Wheel Track: 38 inches (Front)/39 inches (Rear)
Ground Clearance: 7 inches at Differential
POWER
Power Source: 56.7 V DC
Motor Type: AC Induction
Horsepower: 11.7hp Peak
Electrical System: 56.7 V
Battery: Twin Pack
Speed Controller: 235 Amp AC Controller
Drive Train: Motor Shaft Direct Drive
Transaxle: Limited Slip Differential with Helical Gears
Gear Selection: Dash Mount Forward - Neutral - Reverse Key Switch
Rear Axle Ratio: 16.99:1
PERFORMANCE
Seating Capacity: 4-Person
Vehicle Load Capacity: 800 lbs
Outside Clearance Circle: 23.9 feet
Speed: 25 mph
Towing Capacity: 500 lbs
STEERING AND SUSPENSION
Steering: Self-Compensating Rack and Pinion
Suspension: Leaf Springs with Hydraulic Shock Absorbers
Service Brake: Four-Wheel Hydraulic, Front Disk; Rear Self-Adjusting Drum
Parking Brake: Automatic Electro-Magnetic
Tires:Kenda K500 20 x 8-10 (6 Ply)
